Rubber floor mounts
Compact rubber-metal vibration damper for light loads, up to 50 kg per mount.
Deflection VIBS 3-7 Series rubber-metal dampers: compact vibration protection
Deflection VIBS 3-7 Series rubber-metal dampers are designed to protect light industrial and mobile equipment from shock and vibration. They provide effective isolation, even in demanding environments or in transit.
| Model | Mobile application (kg) | (lb) | Static application (kg) | (lb) |
|---|---|---|---|---|
| VIBS-3 | 3–5 kg | 7–11 lb | 10 kg | 22 lb |
| VIBS-4 | 5–10 kg | 11–22 lb | 20 kg | 44 lb |
| VIBS-5 | 10–15 kg | 22–33 lb | 30 kg | 66 lb |
| VIBS-6 | 15–20 kg | 33–44 lb | 40 kg | 88 lb |
| VIBS-7 | 20–25 kg | 44–55 lb | 50 kg | 110 lb |
Maximum load per damper.
It is Deflection’s compact rubber-metal damper for light equipment: 3 to 25 kg per damper in mobile applications, and up to 50 kg in static applications.
Divide the weight of the equipment by the number of support points. Up to 50 kg per point, the VIBS 3-7 Series is suitable. Above that, move to the VIB 1-5 Series, which covers 100 to 1,500 kg per damper.
Yes, the rubber-metal construction is designed for standard plant environments. For corrosive environments, talk to our team.
It depends on inventory. Contact us with the quantity and model required for a precise lead time.
