Floor isolators
SM2 variant of the seismic floor isolator, for loads and configurations different from the SM1.
Deflection SM2 Series isolators: robust vibration isolation
Deflection SM2 Series isolators are designed to reduce vibration from HVAC equipment. Built from solid steel with a powder-coat finish, they include coated steel springs, a leveling device and non-skid pads for a stable installation. With a load capacity of 100 to 2,800 lb, they suit compressors, fans, pumps, air handling units, chillers, cooling towers, condensers and more.
Used for a wide range of HVAC equipment such as compressors, air handling units, fans, pumps and chillers.
| Model | Rated load (lb) | Rated load (kg) | Deflection (in) | Max. horizontal housing (g)* | Spring color |
|---|---|---|---|---|---|
| SM2 100 | 100 | 45 | 2.00 | 26.4 | green |
| SM2 200 | 200 | 91 | 2.00 | 21.0 | yellow |
| SM2 300 | 300 | 136 | 2.00 | 15.1 | dark blue |
| SM2 400 | 400 | 181 | 2.00 | 11.3 | dark brown |
| SM2 650 | 650 | 295 | 2.00 | 7.0 | red |
| SM2 900 | 900 | 408 | 2.00 | 4.8 | dark green |
| SM2 1200 | 1,200 | 544 | 2.00 | 3.6 | orange |
| SM2 1400 | 1,400 | 635 | 2.00 | 3.3 | black |
| SM2 1550 | 1,550 | 703 | 2.00 | 3.4 | grey |
| SM2 1650 | 1,650 | 748 | 2.00 | 3.4 | white |
| SM2 1800 | 1,800 | 816 | 2.00 | 3.4 | purple |
| SM2 2100 | 2,100 | 953 | 2.00 | 2.7 | light green |
| SM2 2200 | 2,200 | 998 | 2.00 | 2.5 | light blue |
| SM2 2500 | 2,500 | 1,134 | 2.00 | 2.5 | light brown |
| SM2 2600 | 2,600 | 1,180 | 2.00 | 2.3 | silver |
| SM2 2800 | 2,800 | 1,270 | 2.00 | 2.2 | maroon |
* Maximum horizontal g-force the housing can withstand.
A spring floor isolator with seismic restraint, for floor-mounted mechanical equipment. It is a variant of the SM1 Series that covers different loads and configurations.
The choice depends on the load per support point and the space available. The PDF technical sheets for both series allow a direct comparison.
Yes, the built-in seismic restraint is designed for Quebec applications subject to seismic requirements.
Use the “Request a quote” button and give the equipment to isolate, its weight and the number of support points.
