Rubber pads
Blue foam damping pad, a cost-effective solution for light vibration damping.
The Deflection Blue Foam Rubber Pad is a general-purpose anti-vibration pad with a ribbed pattern on both sides and a foam middle layer. The middle layer is a closed micro-cellular rubber foam bonded to the ribbed rubber faces. The soft blue middle layer provides excellent acoustical noise control, while the top and bottom rubber faces reduce vibration transfer and ensure a positive grip on foundations and equipment bases.
The BF pad suits applications where bolting is to be avoided and vibration conditions are minor and non-critical. It is also recommended for HVAC equipment, motors, pumps, generators, air-conditioning units, chillers, etc.
| Size (in) | Rated load (lb) | (kg) |
|---|---|---|
| 2 x 2 | 8–80 | 4–36 |
| 3 x 3 | 18–180 | 8–82 |
| 4 x 4 | 32–320 | 15–145 |
| 6 x 6 | 72–720 | 33–327 |
| 12 x 12 | 288–2,880 | 131–1,306 |
| 18 x 18 | 648–6,480 | 294–2,939 |
A blue foam damping pad that offers an economical way to dampen light vibration under small equipment.
For light equipment and low-amplitude vibration, where a simple, economical solution is enough. For heavier loads, move to the RSR, RP or SN families.
Yes, it cuts easily to the required size.
Small shop equipment, light ventilation units, commercial appliances and laboratory equipment.
